Mechanical Presses
TME-L2 Series
2-POINT LINK-MOTION TRANSFER PRESSES
Press capacities range
from 10000 kN to 25000 kN
Descrizione
The TME-L2 presses are characterized by the wide suspension point spacing for increased off-center load capability, a minimal overall clearance to reduce the occurrence of breakthrough, the 8-point square slide guides that limits lateral and longitudinal movement and the tie-rod tightened frame to increase rigidity and precision. The large frame design and the manufacturing processes were revamped in order to accommodate the forming of high-strength materials. The advanced link motion provides a reduced draw speed and constant slide velocity.
AIDA manufactures all the precision parts in-house in order to achieve minimal clearances in critical areas and delivers high-precision forming and high durability by means of a 8-surface slide guide design and a grip-type point design. AIDA TME-L2 presses combines master craftsmanship manufacturing with advanced forming technologies and enables the forming of automotive structural panels and transmission parts.
- Advanced link motion provides a reduced draw speed and constant slide velocity
- A stamping system that enables maximum production diversity and stability
- Overload protector utilizing an advanced metal seal design, offering fast response time for protecting your tooling & press
- Minimal overall clearance to reduce the occurrence of breakthrough
- Easy adjustment to maintain superior parallelism & resistance to off-center loading
- Wide connections spacing, increased off-center load bearing capacity
Specifiche principali
Di seguito le specifiche principali di questa serie di presse.
Per richiedere il pdf di questo prodotto è sufficiente compilare il form a lato.
| Model | TME-L2-10000 | TME-L2-12500 | TME-L2-25000 |
|---|---|---|---|
| Capacity (kN) | 10000 | 12500 | 25000 |
| Slide Stroke (double reduction) (mm) | 550 | 400 | 500 |
| Slide and bolster length (mm) | 4500 | 5100 | 4400 |
| Slide and bolster width (mm) | 1800 | 1800 | 1800 |
| Side window opening (mm) | 2500 | 2360 | 2600 |
| Shut height (mm) | 900 | 900 | 950 |
| Slide adjustment (mm) | 300 | 300 | 300 |
| Press speed in full revolution (double reduction) (mm-1) | 10÷25 | 6÷24 | 8÷30 |
